Additional equipment for karaoke systems

Full HD web-camera with a sensor resolution 1080p

Web камера для караоке системы

LifeCam Studio

Evolution karaoke system is completely adapted to work with Full HD web-cam. You get excellent video quality in Full HD mode with web-cam LifeCam Studio, equipped with a high-resolution sensor in 1080p, as background wallpaper. The auto focus function always provides the highest accuracy in the subject at a distance of 10 centimeters to infinity. Supported shooting with a wide angle lens thanks to high-quality composite LifeCam. In addition, the survey simplifies TrueColor technology that gives the image brightness and iridescence in almost any conditions, and ClearFrame technology ensures smoothness and clarity.

Sensor – CMOS sensor technology.
Resolution – 1920 X 1080, freeze-frame: 5-megapixel (2560 x 2048 pixels, interpolated).
Viewing Angle – 75 ° diagonal.
Features visualization – Automatic face tracking; digital pan, tilt digital and 3x digital zoom; automatic focusing from 0.1 m to 10 m ≥; automatic image adjustment with manual control; up to 30 frames per second.

VGA signal converter 5 composite outputs

Дополнительно оборудование EVC15

Сonverter EVC15

Designed to convert VGA video standard in composite video (Composite, CVBS), and the ramifications of its 5 channels.

Number of inputs – 1.
the input video standard – VGA.
Connector Type – DHR-15 (female).
Input Impedance – 75 ohms.
Swipe (at 75 ohms) – 0.7 V.
Type of synchronization signals – isolated, polarity any.
Supported screen resolutions * – 640×480, 60-85 Hz; 800h600,60-85 Hz; 1024×768, 60-85 Hz; 1280×768, 56-75 Hz; 1280×1024, 60-85 Hz.
(* Progressive scan, the recommended frequency sweep – 60 Hz.)

Number of outputs – 5.
Standard video output – Composite (CVBS).
Connector Type – RCA ( “Tulip”).
TV standard – PAL (B, D, G, H, I).
field frequency – 50 Hz.
Color subcarrier frequency – 4.43 MHz.
Output Impedance – 75 ohms.
Swipe (at 75 ohms) – 1 B.

Dimensions (HxWxD) – 29,5h104h133 mm.
Meals – 5 V (via VGA or USB B).
Maximum current consumption – weight – 190 g
